PRECAST CONCRETE ELEMENTSwww.cpi-worldwide.com CPI %u2013 Concrete Plant International %u2013 1 | 2026 157cycle. For the highest productivity requirements, the PLC AMM models are available with up to 81 fixed weld heads. The PLC AMM models are by far the most productive in this category.%u2022 Any type of mesh can be produced automatically, immediately and without changeover and idle times.%u2022 The line and cross wires are fed into the welding portal immediately by two separate Flexiline rotor straightening and cutting machines with maintenance-free 5G rotors each with eight hyperbolic rollers and with extremely fast diameter change system. The diameter change takes place in less than 3 seconds without mechanical moving parts. Depending on the model, up to six diameters can be processed.%u2022 Direct feeding of the cross wires into the welding portal. The complicated, maintenance intensive and susceptible common cross wire feeding systems, where the cross wires have to be produced first and then the longitudinal wires, as it is the case in the lines with one straightening machine, are no longer necessary.%u2022 Thanks to the innovative concept, the AMM machines are the most compact on the market and have a minimal floor space demand.The machines are offered with unique precision bending systems:%u2022 Integrated, in-line universal bending modules for bending up individually selected line and cross wires, even within openings. The sophisticated design, the drive with servo motors each and the advanced modern software make them the most technically superior in the industry. They are characterized by highest precision and speed. Two bends are performed in 2.5 seconds with consistently precise bending geometry.%u2022 Integrated, in-line mesh bending stations for bending mesh into baskets.%u2022 No idle times during production. During the bending process of one mesh the next one is already in production.%u2022 Connection to master computer for the %u201cJust-In-Time%u201d production, synchronized with circulating pallet systems.%u2022 The AMM welding machines require only one operator.Additionally available optional systems include:%u2022 Robotic transport systems for automatic transfer of produced mesh to circulating pallets.%u2022 Mesh buffer and storage systems nFURTHER INFORMATIONEurobend GmbHAlexanderstr. 190547 N%u00fcrnberg-Stein, GermanyT +49 911 94 98 980info@eurobend.comwww.eurobend.comDetail of bends PLC AMM line with integrated universal bending modules, mesh buffer racks and distribution system on circulating palletsCage production with integrated, in-line mesh bender
